OG8004/P - Lincat Opus 800 Propane Gas Counter-top Boiling Top - W 900 mm - 40.8 kW

Add to Compare
Product ID: OG8004/P

Features & Benefits Overview

Powerful 7.5kW dual concentric Burners for focused heat distribution from a fast boil to a low simmer
Individual heavy-duty single cast iron supports, built to withstand the rigours of the busiest kitchen

Low flue to allow use of the complete hob top
Gas Boiling Tops

Perfect for large pubs and restaurants, school canteens, care homes and hospitals, the Opus 800 Gas 6 x Boiling Top comes with individual heavy-duty single cast iron supports, which are built to withstand the rigours of the busiest kitchen. With powerful 7.5kW dual concentric burners designed for focused heat distribution from a fast boil to a low simmer, you'll be cooking fabulous dishes in no time at all. The Boiling Top also features a low flue to allow use of the complete hob top.

Less

Add on Items

If you wish to purchase additional items, we have an excellent range of model specific add on items that are guaranteed to work with this product. Feel free to select an item from the available options below.

MinimiseAvailable ‘Add-On Items’ for Lincat Opus 800 Propane Gas Counter-top Boiling Top - W 900 mm - 40.8 kW

Lincat Opus 800 Free-standing Floor Stand with Legs - for units W 900 mm

OA8914

View Product

Lincat Opus 800 Free-standing Floor Stand with Castors - for units W 900 mm

OA8914/C

View Product

Lincat Opus 800 Free-standing Pedestal with Doors and Legs - for units W 900 mm

OA8973

View Product

Lincat Opus 800 Free-standing Pedestal with Doors and Castors - for units W 900 mm

OA8973/C

View Product

Less

Specifications

Below you find the product specifications and technical details for our product Lincat Opus 800 Propane Gas Counter-top Boiling Top - W 900 mm - 40.8 kW.

Summary
Brand	Lincat
Range	Opus 800
Power Type	Gas
Gas Type	Propane Gas
Unit Type	Counter-top
Available in UK Only	No
UK Warranty	2 Years Parts and Labour Warranty
Export Warranty	Contact your local dealer
GTIN	5056105102274

Power and Performance
BTU per Hour	139,210
Total Power kW	40.8
Temperature Control	Mechanical
Rating per Hob kW	6.8

Key Specifications
Number of Hobs	6

Weights and Dimensions
Unit Height (External) mm	412
Unit Width (External) mm	900
Unit Depth (External) mm	800
Net Weight Kg	75

Supply Connections
Requires Installation	Yes
Requires Electrical Supply	No
Gas Connection BSP	3/4"
Gas Consumption at full rate Propane m³ per Hour	2.92
Gas Pressure Propane mbar	37
Total heat input at full rate Propane kW	40.2
Total heat input at full rate Propane BTU per hour	137,168

Shipping
Packed Weight Kg	82.5
Packed Height cm	64
Packed Width cm	70
Packed Depth cm	85

Less

Documents & Downloads

For more information on this product, please click on the specific link below to download the required documentation.

Specification Sheet Product Manual Technical Picture CAD/BIM Models
