F78/020 - WastePro II Dewaterer – Right Hand Discharge

Product Model : F78/020

F78/020 - Connected to a suitable existing IMC or alternative brand waste disposer in either a standalone or trough configuration, WastePro II removes excess…

F78/020 - WastePro II Dewaterer – Right Hand Discharge

Product Model : F78/020

F78/020 - Connected to a suitable existing IMC or alternative brand waste disposer in either a standalone or trough configuration, WastePro II removes excess…

Features & Benefits Overview

  • No need to replace existing waste disposer - simply connect to existing waste disposer in either a standalone or trough configuration, with minimal disruption to kitchen
  • Ensures compliance with technical and legal restrictions, where food waste cannot be disposed of via mains drainage
  • Remove excess liquid from food macerated in separate food waste disposer
  • Cost-effective system for many commercial and institutional organisations
  • Right hand discharge

Full Description

WastePro II is ideal in instances where food waste can no longer be disposed of via mains drainage, either due to technical restrictions or legal regulations. The grey water is dispensed direct to drain whilst the solid waste is captured in a lidded bin for subsequent onward processing. The flexibility of WastePro II provides a cost effective system for commercial and institutional kitchens.

Add on Items

We have an excellent range of model specific add on items that are guaranteed to work with this product.

Available ‘Add-On Items’ for F78/020 - WastePro II Dewaterer – Right Hand Discharge

Specifications

Here you find the product specifications and technical details for our product WastePro II Dewaterer – Right Hand Discharge

Energy Type

Electric

Installation Type

Freestanding

GTIN

5056105196976

Kilowatts

1.10

Control Type

On/Off

Product Height (mil)

825

Product Width (mil)

980

Product Depth (mil)

450

Product Weight (kilogram)

84

Professional Installation Required

Yes

Electrical Connection Type

Direct Hardwired

Electrical Watts

1,950

Electrical Phase

Three

Electrical Voltage

400V

Ship Weight (kilogram)

131.30

Ship Height (centimeter)

99

Ship Width (centimeter)

150

Ship Depth (centimeter)

74

Water Line Required

True

Water Connection Source Type

Water Main

Water Inlet Size

0.75

Water Inlet Pressure Minimum

0.18

Drain Line Required

True

Drain Outlet Size

2

Motor Power (horsepower)

0.50

Operating Noise Level (decibel)

83

Drip Pan

False

Operator Safety Method

User Guide

Documents & Downloads

For more information on this product, please click on the specific link below to download the required documentation.

IMC_F78_020_AutomatedSpecSheet
IMC WasteStationRange Discharge Manual 1
